After enough SFMC engagements, you start to recognize that Automation Studio builds are mostly combinations of six patterns. Knowing them - plus the trigger and Activity options underneath - lets you scope a new build in 30 minutes.
Here's the reference we hand to every new engineer.
Pick the Starting Source first
| Starting Source | Trigger | Use when |
|---|---|---|
| Schedule | Fixed clock | You know the run time exactly (daily 8am, Mondays, 1st of month) |
| File Drop | New file lands in SFTP folder | Upload timing isn't fixed |
| API | External system calls SFMC REST API | Real-time triggered by another system (website checkout, CRM event) |
Getting the Starting Source right prevents 80% of reliability issues. Schedule with a file dependency is the #1 source of "ran with yesterday's data" bugs.
Then pick the Activities
| Activity | Purpose |
|---|---|
| Import File | Read a CSV from SFTP, write rows into a DE |
| SQL Query | Join, filter, transform, aggregate data across DEs; write result to a DE |
| Filter | Refresh a Filtered Group or Filtered DE from a predefined Data Filter |
| Data Extract | Turn a DE into a CSV on SFMC SFTP |
| File Transfer | Move, encrypt, decrypt, or push files between SFTP locations |
| Send Email | Send from a DE to an email asset |
| Verification | Check record count in a DE; halt automation if out of range |
| Wait | Pause before the next step |
Most production automations chain 2-5 of these. Keep each automation focused; complex flows become three simpler automations chained via a Parent/Child pattern.
The six patterns you'll use every month
Pattern 1: Daily import + send
Schedule -> Import File -> Send Email
The simplest automation. Client uploads file on a dependable schedule, you import and send from it. Use Schedule if the upload time is fixed; otherwise switch to File Drop.
Pattern 2: File drop with encryption
File Drop -> File Transfer (decrypt PGP) -> Import File -> Send Email
Client delivers encrypted files. File Transfer decrypts into the Safehouse, Import File reads from there, Send Email runs.
Pattern 3: Nightly export to external SFTP
Schedule -> SQL Query -> Data Extract -> File Transfer
The one we covered in the export post. SQL Query filters the data, Data Extract writes it to SFMC SFTP, File Transfer pushes it to the client's SFTP.
Pattern 4: Production-safe import (with Verification)
File Drop -> Import File -> Verification -> Send Email
Adds a Verification Activity between Import and Send. If the imported row count is out of the expected range, the automation halts and sends an alert instead of emailing bad data.
Pattern 5: Send Log archive
Schedule (daily at 1am) -> SQL Query (copy yesterday's _SendLog rows into archive DE)
Used anywhere the client needs send history beyond the default 10-day retention. Same pattern works for _Open, _Click, _Bounce.
Pattern 6: Encrypted export
Schedule -> SQL Query -> Data Extract -> File Transfer (encrypt) -> File Transfer (push to external SFTP)
When the client requires PGP-encrypted output. Two File Transfer Activities: one to encrypt the file, one to push it.
Wiring patterns together
Individual automations are composable. A common chained setup on enterprise engagements:
Automation A (nightly ingestion): File Drop -> Verification -> Import File -> SQL Query (populate Audience_DE)
Automation B (morning send): Schedule -> SQL Query (final segmentation) -> Send Email
Automation C (evening export): Schedule -> SQL Query -> Data Extract -> File Transfer
Three automations, separate concerns, each one small and debuggable. Alternative: one monster automation with 15 steps that nobody wants to read. Separate concerns.
Where to put the Verification
Rule of thumb: any automation that ends in a Send Email Activity AND imports from a file should have Verification between them. Files fail in too many ways for the Send to be unprotected.
Takeaway
Every SFMC Automation Studio build you'll ever do is a remix of these six patterns. The Activity list is short, the Starting Sources are three, and most production mistakes come from picking the wrong Starting Source or missing a Verification step. Pin this reference somewhere visible and you'll scope new builds faster than the client can finish describing them.
